Description
This Allows You To Split A Single Plug Into 2 Allowing You To Run Multiple Driving/Work Lights Off The Same Switch And Harness.
Compatible With All Lightforce Wiring Harnesses Using A Dt Style Connector - Striker Harness (Strikerledharn) Rok Harness (Cbrokh) And Led Bar Harnesses From 6 To 20 In Length.
Connect Multiple Lights Using A Single Harness
This Allows You To Split A Single Plug Into 2 Allowing You To Run Multiple Driving/Work Lights Off The Same Switch And Harness.
This Harness Allows For The Connection Of Two Accessory Lights, Using A Single Input On A Range Of Our Wiring Harnesses, Male ; Female Plugs Connect Directly From The Harness Into The Back Of The Lights.
Compatible With All Lightforce Wiring Harnesses Using A Dt Style Connector - Striker Harness (Strikerledharn) Rok Harness (Cbrokh) And Led Bar Harnesses From 6 To 20 In Length.
For Example, Using Our Standard Striker Led Harness You Can Fit An Additional 2 Led Strikers On The Existing Harness Resulting In 4 Led Strikers To Be Used On The Supplied Harness Reducing The Need To Run Additional Wiring.
Specifications:
- 18awg Cable
- Waterproof Dt Style Connectors
- Cable Contained In Braided Sleeve
- Cable Lengths Are 300mm
- Total Current Rating 10amps @13.2 Volts
Note: Always Ensure Your Original Harness Is Rated To Handle The Increased Load (Current) When Adding Additional Lights And If Required The Fuse Replaced With A Suitable Rating.
